Golden Technologies

Golden Tech Compass HD Power Wheelchair, 450 lb. Cap, Heavy Duty Frame, Captain Seat, 4 MPH (GP620)

$5,426.00
$5,426.00
$6,599.00
Shipping calculated at checkout.
Color: Red
Seat Size:
Contact Sale Team To Learn More

The heavy-duty version of the original Compass offers users a robust 450 lb. weight capacity with all of the same great features including the patented springless articulating chassis and true center-wheel drive design for unmatched maneuverability in tight spaces. The Compass HD comes in a variety of seat sizes up to 24ā€ wide.

Key features

  • Weight Capacity:Ā 450 lbs
  • Length:Ā 40ā€³
  • Width:Ā 25ā€³
  • Operating Range:Ā 12 miles
  • Maximum Speed:Ā 4 mph
  • Ground Clearance:Ā 3.5ā€³
  • Turning Radius:Ā 20ā€³
  • Length:Ā 40ā€³
  • Width:Ā 25ā€³
  • Number Seat Height Positions:Ā 5

Available Accessories:

  • Captainā€™s Seat
  • Swing-away legrests
  • Elevating legrests
  • Stump support
  • Footplate extender
  • Cane/crutch holder kit
  • Walker holder kit
  • Oxygen tank holder kit
  • Pack N Go

Ā
  • User Weight Capacity: 450 lbs
  • Drive Wheels: Center
  • Maximum Speed: 4 mph
  • Operating Range: 12 miles
  • Ground Clearance: 3.5"
  • Turning Radius: 20"
  • Type Batteries: NF22
  • Standard Colors: Red, Blue
  • Freewheel Mode: Yes
  • Electronic Speed Control: Yes
  • Electro-Mechanical Brakes: Yes
  • Charger: Off Board
  • Controller: 75 Amp
  • Length: 40"
  • Width: 25"
  • Height (ground to top of back of seat): 38.25ā€ ā€“ 42.75ā€
  • Height (ground to top of back of headrest): 47"-53"
  • Ground to Top of Seat: 21.25ā€ ā€“ 24.25ā€
  • Number Seat Height Positions: 5
  • Size of Increments: 0.5"
  • Weight of Unit (assembled): 226 lbs
  • Base Weight: 101 lbs
  • Seat with Arms Weight: 51 lbs
  • Batteries Weight: 37 lbs ea
  • Tires (standard): Flat Free / Non Marking Solid
  • Center Tire: 10"
  • Casters: 6"
  • Standard Seat: Captain's Seat
  • Back Height (no headrest): 19"
  • Back Height with Headrest: 26.5"-30"
  • Seat Width x Depth: 18"-24"x18"-20"
  • Seat Color: Black Vinyl
  • Optional Seat: Captain's Chair
  • Optional Seat 2 Back Height (no headrest): 19"
  • Optional Seat 2 Back Height (with headrest): 26.5"-30"
  • Optional Seat Width x Depth: 18"-24"x18"-20"
  • Optional Seat Color: Black Vinyl
  • Footrest Height Adjustable: Yes
  • Footrest Angle Adjustable: Yes
  • Warranty Frame: 5 Years
  • Warranty Drive Train: 13 months
  • Warranty Electronics: 13 months
  • Warranty Batteries: 1 year

Return Info

  • 25%-50% Restocking Fees
  • Bed Frames Scooters, Power Wheelchairs, Wheelchairs, Lifts, Rollators, Accessories
  • Delivery fee ($120) and Pickup Fee ($80)

Subject tp Review / NON-Returnable

  • Custom made products
  • Lift Recliners (due to hygeine safety)
  • Mattresses (due to hygeine safety)
  • Bath Safety, used (due to hygeine safety)
  • Retail packaged products, unboxed/used
Review all policies
